Precision-extruded unequal angle in 6060 alloy, available cut to length.

Download PDF

Unequal angle.

View the full specification table, or download the PDF version using the button provided.

Download PDF

Section	Ex stock	Size mm			Radii mm (E/I)	Kilo / metre	Perimeter mm
Section	Ex stock	A	B	T	Radii mm (E/I)	Kilo / metre	Perimeter mm
60092	*	20.00	12.00	1.40	0.20 (E)	0.115	63.6
30871	✓	20.00	12.00	1.60	0.30 (E)	0.131	63.4
60216	*	20.00	16.00	3.00	0.30 (E)	0.268	71.4
60093	*	25.00	12.00	1.40	0.20 (E)	0.134	73.6
10161	✓	25.00	12.00	1.60	–	0.153	74.0
60139	*	25.00	12.00	3.00	0.20 (E)	0.276	73.6
30020	✓	25.00	20.00	1.40	0.20 (E)	0.165	89.4
60165	*	25.00	20.00	3.00	0.30 (E)	0.341	89.4
60062	*	30.00	20.00	1.30	0.30 (E)	0.171	99.4
30922	*	32.00	19.00	3.00	0.20 (E)	0.390	101.6
60009	*	32.00	20.00	1.40	0.30 (E)	0.192	103.4
60121	*	32.00	20.00	1.40	0.20 (E)	0.192	103.6
30671	✓	32.00	25.00	1.50	0.20 (E)	0.205	103.6
60241	*	32.00	25.00	3.00	0.30 (E)	0.439	113.6
30489	*	35.00	10.00	3.00	0.20 (E)	0.341	89.6
60089	*	38.00	30.00	2.40	0.30 (E)	0.426	135.4
60113	*	40.00	10.00	3.00	0.50 (E)	0.381	98.9
60283	*	40.00	12.00	3.00	0.25 (E)	0.398	103.5
20494	*	40.00	18.00	1.50	0.20 (E)	0.230	115.6
10162	✓	40.00	20.00	1.50	–	0.238	120.0
60085	✓	40.00	20.00	5.00	Full radius	0.727	114.6
60114	*	40.00	25.00	1.40	0.20 (E)	0.241	129.6
90075	*	40.00	25.00	1.60	–	0.275	130.0
30664	✓	40.00	25.00	3.00	0.20 (E)	0.504	129.6
60087	*	50.00	25.00	1.40	0.20 (E)	0.279	149.6
10163	✓	50.00	25.00	1.60	–	0.318	150.0
30895	✓	50.00	25.00	3.00	0.20 (E)	0.585	149.6
60173	✓	50.00	40.00	5.00	0.20 (E)	1.152	179.6
60158	*	60.00	40.00	3.00	0.30 (E)	0.788	199.4
60115	*	70.00	25.00	1.40	0.40 (E)	0.355	189.1
60200	*	70.00	25.00	1.50	0.30 (E)	0.380	189.4
60256	✓	75.00	25.00	1.50	0.30 (E)	0.400	199.4
30573	✓	75.00	25.00	3.00	0.20 (E)	0.789	199.6
30592	✓	75.00	50.00	3.00	0.50 (E)	0.991	248.9
30806	✓	75.00	50.00	4.50	0.20 (E)	1.469	249.6
31040	✓	75.00	50.00	6.00	0.30 (E)	1.935	249.4
60100	*	92.00	20.00	3.00	0.20 (E)	0.886	223.6
60260	✓	100.00	25.00	3.00	0.50 (E)	0.991	248.9
30642	✓	100.00	50.00	2.00	0.30 (E)	0.802	299.4
30088	✓	100.00	50.00	3.00	–	1.195	299.5
30509	✓	100.00	50.00	6.00	0.50 (E)	2.341	298.9
60066	*	100.00	75.00	6.00	0.50 (E)	2.747	348.9
90407	*	100.00	75.00	8.00	–	3.621	350.0
60282	*	100.00	75.00	12.00	0.25 (E)	5.301	349.5
60185	*	125.00	75.00	5.00	0.30 (E)	2.642	399.4
60199	*	130.00	50.00	2.00	0.30 (E)	0.964	359.4
60258	*	130.00	37.00	8.00	0.30 (E)	3.447	333.4
60101	✓	150.00	75.00	6.00	0.30 (E)	3.561	449.4
60240	✓	150.00	75.00	8.00	0.30 (E)	4.704	449.4
60284	✓	150.00	100.00	3.00	0.25 (E)	2.008	499.5
30696	✓#	160.00	40.00	1.80	0.20 (E)	0.965	398.4

A = Width, B = Height, T = Thickness, R (E) = external radii. * = mill runs only, please ask regarding availability. ✓ = ex stock. ✓# = ex stock, other stock lengths available in this size, please enquire if the length you require isn't listed.
